MACROMOVER
503-488-5725
Engine Type 110cc,
single cylinder,
4-stroke, air-cooled,
Power rating 4.6kw/7500rpm Max
torque 6.5N.m/7500rpm
Ignition CDI 12V System
Battery 12V.9Ah
Transmission Three speed
Semi-Automatic with reverse, Chain
drive
Fuel tank capacity 2 L
Unleaded gasoline above
No.90
Starting Electric start
Max. speed 31 MPH
Wheel bases 50.0 in
Seat height Ground to top of seat
26 in
Min ground clearance 5 in
Distance between front wheels
39.75 in
Distance between rear wheels
32.25 in
Tire front 14.5x 6- 6/
Tire rear 16 x 6- 7
Brake Front Hydraulic
Brake Rear Hydraulic
Net wieght 325.5 Lb
Gross wieght 400 Lb
Max. load capacity 330.4 pound
Overall size 68.9x46.0x53.3in
Carton size 68.9x44.9x25.0 in
Pallet 3 Pcs
Container 52 pcs /40' HQ
single cylinder,
4-stroke, air-cooled,
Power rating 4.6kw/7500rpm Max
torque 6.5N.m/7500rpm
Ignition CDI 12V System
Battery 12V.9Ah
Transmission Three speed
Semi-Automatic with reverse, Chain
drive
Fuel tank capacity 2 L
Unleaded gasoline above
No.90
Starting Electric start
Max. speed 31 MPH
Wheel bases 50.0 in
Seat height Ground to top of seat
26 in
Min ground clearance 5 in
Distance between front wheels
39.75 in
Distance between rear wheels
32.25 in
Tire front 14.5x 6- 6/
Tire rear 16 x 6- 7
Brake Front Hydraulic
Brake Rear Hydraulic
Net wieght 325.5 Lb
Gross wieght 400 Lb
Max. load capacity 330.4 pound
Overall size 68.9x46.0x53.3in
Carton size 68.9x44.9x25.0 in
Pallet 3 Pcs
Container 52 pcs /40' HQ
7931 Se King Rd.
Milwaukie, Or. 97222
